Briggs 8.75 TP Professional Series Engine HF 7/8" x 1-13/16" #124P02-0002

Save 4%
Briggs & StrattonSKU: 124P02-0002

Price:
Sale price$379.00 Regular price$395.00
Stock:
In stock (44 units), ready to be shipped

Description

Professional Series

8.75 Gross Torque*

The Professional Series engines were designed to deliver a best-in-class experience combining power, performance, features, and size. These engines offer consumers and professionals commercial-grade features including easier starting, smoother and quieter operation, increased durability, and longer life. ReadyStart® is standard on all Professional Series engines.




Briggs 8.75 TP
Professional Series
7/8" x 1-13/16" shaft, tapped 3/8"-24 with 3/16" keyway.
Non-compliance engine, heavy flywheel.
Fixed Speed Throttle design
Universal replacement engine for pressure washers, log splitters, and other types
of engines that do not need a flywheel brake, or that have a mower blade attached.
Ready Start, no choke- no priming.
2 year consumer/ 1 year commercial warranty.
3900 rpm top speed setting.
Model 124P02-0002
36 lbs



Engine Specifications

SKU 124P02-0002-F1
Model/Type/Trim 124P02-0002-F1
Air Cleaner Foam
Carburetor ReadyStart - Full System
Casing Clamp Without
Controls Fixed Speed
Crankshaft Straight 7/8" Dia - 1.812" PTO
Crankshaft Details 3/16" Keyway, 3/8-24 UNF-2B
Emissions Certification EVAP/EXH/EU
Engine Base Standard (Non Flange Mount)
Engine Package 875 EXi Series
Engine Sold In United States
Engine Speed 3900 +/- 0100 RPM - No Load
Flywheel Heavy - Cast Iron
Fuel Cap Black 1/4 Turn
Fuel Tank EVAP
Label Power Without, OEM to Install
Muffler Guard Stamped
Oil Dipstick Extended - Yellow Cap
Oil Drain Without, Check & Add
Rewind Position 5:30

Technical Specifications

Model Series 124P
Power Lbs/Ft of Torque 8.75
Engine Series 875
Displacement 190
Oil Capacity 20 oz (0.59)
Valve Configuration OHV
Flywheel Torque 60 lb/ft (81.3 Nm)
Governor Arm Torque 30 lb/in (3.4 Nm)
Carb Mount 60 lb-in (6.8 Nm)
Plug Gap 0.02 in (0.50 mm)
Intake Valve .004-.008 in (.10-.20 mm)
Exhaust Valve .004-.008 in (.10-.20 mm)
Idle Speed 1750
Air Gap .010-.014 in (.25-.36 mm)
Connecting Rod Torque 97.5 lb/in (11.0 Nm)
Sump Torque 110 lb/in (12.4 Nm)
Head Torque 210 lb/in (23.7 Nm)
Top No Load (rpms) 3900 +/- 0100 RPM - No Load
