Briggs & StrattonSKU: 543777-3222
Price:
$2,399.00
Stock:
In stock (6 units), ready to be shipped

Description

Briggs & Stratton 896cc Vertical Engine 32 HP Vanguard OHV Big Block 1-1/8" x 4-1/2" #543777-3222
32hp Briggs Vanguard OHV
BIG BLOCK!
1-1/8" x 4-1/2" keyed shaft, tapped 7/16.
Cast iron sleeves, electric start w/ 20amp alternator,
full pressure lube w/ oil filter, oil cooler and fuel pump.
Less fuel tank.
Universal replacement engine for premium lawn and
garden and industrial/commercial applications.
Model 543777-3222.
135 lbs

Engine Specifications

SKU 543777-3222-J1
Model/Type/Trim 543777-3222-J1
Air Cleaner Cyclonic with Rain Cap Loose
Alternator 20 amp
Crankshaft Straight 1 1/8" Dia - 4.5" PTO
Crankshaft Details 1/4" Keyway, 7/16-20 UNF-2B
Emissions Certification EPA Cert-Not For Sale In Calif
Engine Idle Speed Governed Idle 1750 +/- 100 RPM
Engine Package Vanguard
Engine Sold In United States
Engine Speed 3700 +/- 0100 RPM - No Load
Flywheel Heavy - Cast Iron
Fuel Line 7.5" with 20 Micron Filter
Fuel Pump Installed
Fuel Tank Without
Label Power Vanguard 896cc 32GHP
Lubrication Full Pressure Lube
Oil Cooler Installed
Oil Drain Dual - M14 Threads Both Sides
Oil Pressure Switch Oil Pressure Switch 7-10 PSI
Purge Port Low Vac Capped,Connector Loose
Wire Harness 8 Pin
